Time to upscale your display
Samsung’s new QBT-B series displays cut through the clutter to deliver best-in-class UHD resolution as well as intelligent UHD upscaling and rich flawless colors with Dynamic Crystal Color all in a slim design.
Incredible 4K picture quality
Empower your customers to experience pure visual innovation with lifelike images in sharper picture quality than ever before.
Marvel at the lifelike Color expression
Dynamic Crystal Display
Immerse your customers in every picture with a wider range of color. Dynamic Crystal Display creates lifelike images allowing the viewer to see even the subtlest details.
Perfect view with non-glare display
The QBT-B series features reliable, non-glare panels that provide better visibility from all angles, anytime of day allowing businesses to deliver accurate information 24/7 in locations where clear and accurate information is crucial such as airports and commuter stations.
Slim and symmetrical design
Slim, symmetrical design that will stand the test of time and ensure the QBT-B series blends seamlessly into any environment, with simple installation to get your display up and running as soon as possible.
Clean cable management
With QBT-B's new cable guide feature, retailers are able to tuck away messy cables from view. This allows for a clean and visually-appealing shopping expeience for customers, even when the back of the display is visible.
Powerful, all-in-one solution
SSSP is an all-in-one solution that simplifies installation and maintenance. With Tizen 4.0, businesses can enjoy easy development, reinforced capability with multiple web formats and standards and secured protection.
Display
Panel type: IPS
Display diagonal: 2.49 m (98")
Display technology: LCD
Display resolution: 3840 x 2160 pixels
Display brightness: 350 cd/m²
HD type: 4K Ultra HD
Response time: 8 ms
Contrast ratio (typical): 1200:1
Dynamic contrast ratio marketing name: Mega Contrast
Viewing angle, horizontal: 178°
Viewing angle, vertical: 178°
Pixel pitch: 0.5622 x 0.5622 mm
Native refresh rate: 60 Hz
Haze rate: 25%
Pixel frequency (max): 594 MHz
Colour gamut: 72%
Ports & interfaces
HDMI ports quantity: 2
HDMI version: 2.0
HDMI input ports quantity: 2
Feature: DVI port
DisplayPorts quantity: 1
DisplayPorts in: 1
DisplayPort version: 1.2
Feature: USB port
USB ports quantity: 2
Feature: Ethernet LAN
Ethernet LAN (RJ-45) ports: 1
Feature: Wi-Fi
Feature: RS-232 interface
Feature: Infrared data port
Remote (IR) input: 1
Design
Product design: Digital signage flat panel
Placement supported: Indoor
Product colour: Black
Screen shape: Flat
Feature: VESA mounting
Panel mounting interface: 800 x 400 mm
Bezel width (bottom): 1.79 cm
Bezel width (side): 1.79 cm
Bezel width (top): 1.79 cm
Bezel colour: Charcoal Black
Performance
Purpose: Universal
Feature: HDCP
HDCP version: 2.2
Power
Power consumption (typical): 462 W
Power consumption (sleep): 0.5 W
AC input voltage: 100 - 240 V
AC input frequency: 50 / 60 Hz
Computer system
Feature: Computer system
Computer system type: System on Chip (SoC)
Feature: Built-in processor
Operating system installed: Tizen 4.0
Weight & dimensions
Display width: 2195 mm
Display depth: 96 mm
Display height: 1250 mm
Display weight: 83 kg
Packaging data
Package width: 2369 mm
Package depth: 350 mm
Package height: 1405 mm
Package weight: 106 kg
Operational conditions
Operating temperature (T-T): 0 - 40 °C
Operating relative humidity (H-H): 10 - 80%
Certificates
Certification: Class A60950-1, 62368-1
Logistics data
Harmonized System (HS) code: 85285210
Technical details
Audio out (mini jack): 1
Other features
Feature: Audio input
Flash memory: 8000 MB
RS-232 input ports: 1
RS-232 output ports: 1
Feature: Video out
RJ-45 input ports: 1
Optional features: WMN8200SG
Samsung QB98T-B. Product design: Digital signage flat panel. Display diagonal: 2.49 m (98"), Display technology: LCD, Display resolution: 3840 x 2160 pixels, Display brightness: 350 cd/m², HD type: 4K Ultra HD. Wi-Fi. Operating system installed: Tizen 4.0. Product colour: Black
SAMSUNG
MBR CODE - LH98QBTBPGCXEN
EAN - 8806094096088
