Display
Display diagonal: 68.6 cm (27")
Display resolution: 3840 x 2160 pixels
HD type: 4K Ultra HD
Native aspect ratio: 16:9
Display technology: LED
Panel type: IPS
Backlight type: LED
Display brightness (typical): 350 cd/m²
Response time: 10 ms
Screen shape: Flat
Supported video modes: 480i, 576p, 720p, 1080i, 1080p
Contrast ratio (typical): 1000:1
Maximum refresh rate: 60 Hz
Viewing angle, horizontal: 178°
Viewing angle, vertical: 178°
Display number of colours: 1.073 billion colours
Pixel pitch: 0.155 x 0.155 mm
Pixel density: 164 ppi
Viewable size, horizontal: 59.6 cm
Viewable size, vertical: 33.5 cm
Digital horizontal frequency: 15 - 135 kHz
Digital vertical frequency: 23 - 61 Hz
Colour gamut standard: Adobe RGB
sRGB coverage (typical): 100%
Adobe RGB coverage: 99%
DCI-P3 coverage: 98%
Performance
Feature: Flicker-free technology
Design
Market positioning: Graphics design
Product colour: Black
Ports & interfaces
Feature: Built-in USB hub
USB hub version: 2.0 / 3.2 Gen 1 (3.1 Gen 1)
Number of upstream ports: 2
USB Type-A downstream ports quantity: 4
Feature: USB Type-C DisplayPort Alternate Mode
USB Power Delivery up to: 60 W
Feature: HDMI
HDMI version: 1.4
DisplayPorts quantity: 1
DisplayPort version: 1.3
Feature: HDCP
Ergonomics
Feature: VESA mounting
Panel mounting interface: 100 x 100 mm
Feature: Height adjustment
Adjustable height (max): 15.5 cm
Feature: Pivot
Pivot angle: 0 - 90°
Feature: Swivelling
Swivel angle range: 0 - 344°
Feature: Tilt adjustment
Tilt angle range: -5 - 35°
Feature: On Screen Display (OSD)
On Screen Display (OSD) languages: German, English, Spanish, French, Italian, Japanese
Number of OSD languages: 8
Power
Energy efficiency class (SDR): G
Energy consumption (SDR) per 1000 hours: 38 kWh
Power consumption (typical): 37.8 W
Power consumption (standby): 0.5 W
Power consumption (max): 168 W
AC input voltage: 100 - 240 V
AC input frequency: 50 - 60 Hz
Energy efficiency scale: A to G
European Product Registry for Energy Labelling (EPREL) code: 356566
Weight & dimensions
Width (with stand): 638 mm
Depth (with stand): 265 mm
Height (with stand): 559 mm
Weight (with stand): 10.3 kg
Width (without stand): 638 mm
Depth (without stand): 75 mm
Height (without stand): 378.2 mm
Weight (without stand): 6.7 kg
Packaging data
Package type: Box
Packaging content
Cables included: AC, DisplayPort, USB Type-C
Other features
Feature: Hardware calibration
Compliance certificates: RoHS
Logistics data
Harmonized System (HS) code: 85285210
EIZO ColorEdge CS2740. Display diagonal: 68.6 cm (27"), Display resolution: 3840 x 2160 pixels, HD type: 4K Ultra HD, Display technology: LED, Response time: 10 ms, Native aspect ratio: 16:9, Viewing angle, horizontal: 178°, Viewing angle, vertical: 178°. Built-in USB hub, USB hub version: 2.0 / 3.2 Gen 1 (3.1 Gen 1). VESA mounting, Height adjustment. Product colour: Black
Eizo
MBR CODE - CS2740
EAN - 4995047055624
